Adventures Are Not On Any Map (but a good GPS doesn’t hurt)

August 20th, 2010 · How To Info

I like maps!  I’ll spend hours in map stores, looking, touching, smelling maps, planning off road adventures.  Maps are great!

I like maps… But I love technology.  Now before you scream about technology on an off road adventure failing, breaking, getting dusty and wet or  how the battery can die off, I always carry hard copies of maps stored water tight with a compass…  and I know how to use them.

In order to get a technology fix we decided to build our own mobile satellite GPS tracking command center that can be loaded up with high quality maps of areas we want to explore.  Sure we have Brenda our Garmin GPS (or a close facsimile of her following the 2009 abduction incident), but we wanted something we could load trail routes into, create tracks, pin point ourselves on multiple maps and display higher resolution of 4×4 trails.  Turns out it is not that hard to take an old lap top, some open source software along with a few bits and turn it into GPS Central.

When we set out to build our GPS system we had a few requirements for this build:

  1. has to be cheap or better yet… free
  2. must work with maps from several sources
  3. maps must be free and unencumbered by copyrights
  4. needs to be capable of working on-line or off line (sure the internet is in Chicken, AK. but some of these places are still passing messages by carrier pigeons)
  5. easy to use, easy to read, easy to zoom in tight, easy to zoom out big, easy, easy, easy

With our requirements in hand the first thing to do was decide how to make it all happen.  This is where we insert a big thank you to Jeff Baker from the NWFJCC.  We rode his technical coattails all the way on this mod.

Following Jeff’s lead we made a list of needed stuff:

  • old laptop
  • Operating system
  • GPS software
  • Waterproof GPS Receiver

The old laptop:  You would be surprised at how easy it is to scrounge an old laptop. Now you’re not going to end up with a 3.4 GHz Hyper-Threading quad proc, quad core, with 32 Gigs of ram, dual 10,000 rpm raid five disk set, HD graphics advanced video engine, or 7.1-channel Dolby audio but check with your techie friends.  You don’t need much for this build and tech guys are always cycling through the latest and greatest, discarding leftovers in their path.  We ended up with an old HP Pavilion.

Operating system: the open source movement really began with Linux, a Unix like operating system that came into the world in 1991 and spread through the Internet faster than a leveraged buyout rumor on Wall Street’s trading floor.  While Linux will fly on butch hardware it was designed to run on more modest equipment and is perfect for use on an old recycled laptop. There are several Linux flavors available: RedHat, SUSE, Debian, Fedora, Ubuntu…  you get the picture.  All the distributions use the same basic Linux kernel and than add their own set of libraries, tools and software, packaging it all up under their brand name.  Some of the distributions are commercial but many are free.  In a past life as a software developer, I’ve used many of the different distributions and it is amazing how far they have come with ease of installation, rock solid updates, intuitive desktops, do anything software and geeky cool factor.  Today there are really good distributions that are community supported and free.  Remember requirement number one.

The Ubuntu distribution is simple and quick to install with a desktop that is intuitive.  The interweb (that is for all our Corner Gas Canadian friends) is full of helpful forums and instructions on installing and using Ubuntu so answers to questions are everywhere.  Installing software packages like web browsers, games, DVD players, email, word processing, spreadsheets, picture editors or instant messaging chat,  is just as easy.  Ubuntu is the distribution I always suggest to non-technical folks looking to try Linux.

Ubuntu took about 30 minutes to install. Really that was it.  Next task, the gps software that would be the cornerstone of the operations.

GPS software: there are a number of free mapping software packages available out there.  We decided to go with tangoGPS since it was one of the easier ones to work with.  It wont do everything some of the other packages will but it does all the stuff on our list.  A big selling point for us was the ability to work with open source maps (OSM) as well as Google Maps, Opencyclemap and others.  As new map sources become available you can configure tangGPS to use them.  Jeff found one source that takes OSM maps and layers them over GIS Topo maps.  Simply add a new map type in the tangoGPS configuration tab and point to its URI (uniform resource identifier).  In this case it was: “http://mobilemap.petschge.de/topomirror.php?z=%d&x=%d&y=%d”

Each mapping project tends to focus on different aspects when creating their maps such as roads, businesses, trails or what not.  With the ability to use multiple maps you can see your location from different perspectives and verify the information across multiple sources.  The image below shows four different map sources at the same level of detail for the same location.

When you are connected to the Internet, tangoGPS can automatically down load map tiles (fancy term for little picture) as needed.  These same cached map tiles are than available to you when you are off line.  If you’re not sure of exactly where you will be exploring in a particular area you can zoom out and down load all the tiles of that area.  We downloaded all the map tiles for the Olympia Mountains (about a 1,000 square mile area)…  it took 22 hours and we have a fast connection!  There is are several levels of detail and you can choose to down load some or all of them.

tangoGPS is one of the applications in the Ubuntu App Manager which means installation is simply clicking on the install button, making it extremely easy to install or remove.  Navigation within and Configuration of tangoGPS are straightforward as well.

There is even a “Friends” option which, if you have an Internet connection, will allow you to publish your location and leave a message to a website letting friends know you’re OK.

When you install tangoGPS, the App Manager also downloads the GPS demon (Unix speak for program) known appropriately as gpsd.  This little demon allows you to hook up and integrate a GPS satellite receiver with tangoGPS.  By integrate I mean plug-in, tangoGPS takes it from there.  With a GPS satellite receiver (or two) tangoGPS locates you on the maps, allowing you to track your movements, create bread crumb trails (record way-points) and view information such as your longitude, latitude, heading, elevation and speed.

It is at this point we hit the wall with free.

GPS Receiver: Obtaining a GPS receiver required us to crack the piggy bank. If we were going to get the most out of our system this was a must have item.  Fortunately for the little piggy a GlobalSat BU-353 Waterproof USB GPS Receiver was only $37.50.   Certainly there are more expensive receivers, but this little unit worked great.  And with it’s USB connector, integrating it with our laptop couldn’t be simpler.

The GlobalSat receiver came with a little suction cup and has a magnet in its base so you can attach it just about anywhere.

After plugging in the GPS receiver and starting up tangoGPS everything should just work.  Last great software lie right.  Well it did for us.  If you run into any problems with your receiver or want a view of what is going on with it you can peer into the black hole and eaily test it.  Plug in the GPS receiver and start the GPS demon with the following command: gpsd /dev/ttyUSB0 Than start up the simple viewer called xgps.  You may need to add this program using the Ubuntu app manager if you did not add it when installing the tangoGPS package.  To start the viewer type xgps on the command line.  xgps will display a window showing the satellites available to the receiver, their signal strength and location.  It will also show you the information that gpsd is parsing out.

Getting this all to work sitting on the back deck is one thing, having it work while driving 70 mph down the highway is another.  To put our new GPS system through its paces we decided to drag it with us on a recent off road camping and fishing adventure.  We loaded the maps from Seattle, WA to Eugene, OR and the areas surrounding the north fork of the Willamette River. The system worked better than expected.  In our test we stuck the lap top in the passenger’s seat with the GPS receiver tossed up on the dash.  The system tracked our every movement, keeping our position centered in the screen, clearly showing details that are lost on the smaller GPS units.  The GPS and maps lined up exactly and with a single mouse click we could zoom in or out without missing a beat.

There is one small issue to get used to with a system like this.  Driving at night, a 17 monitor will illuminate everything around it and more often than not as we passed others on the highway, heads turned as they noticed the glow emanating from the passengers seat.  At the rest stops, several folks would wonder over to get a better look at the system, ask about it and inquire where we were heading.  But this is a small price to pay for a GPS system that can do so much and cost sooooo little.  Now to try it out on a worthy adventure.

Bookmark and Share

Welcome back... drop us a note about one of your adventures... we'd love to publish your story along with your pictures.


→ 7 CommentsTags: ········

River of Change

August 11th, 2010 · Rants, Raves and the Zen Art of Road Trip Management

The second universal truth of the Buddha is that everything is continuously changing. Life is like a river flowing, ever-changing. It flows slowly and sometimes swiftly. It is smooth and gentle in some places, it snags on rock crops out of nowhere. As soon as you think you are safe, something unexpected happens.

Pain finds men no matter where they are, no matter how good they are, how hard they try. Struggling to make ends meet, make relationships connect, make life work out. Men live on a piece of rock that makes us weak.

Some, find a friend, a brother, to lean on. A brother in arms to help in the struggle, to stand shoulder to shoulder in the battle for life. A brother who, without question will lay down his life for another. A man who will walk the road of hell because someone is needed to point to the light, calm trembling eyes and show the way out.

These are not just words rolling about in the sunrise. These are echoes of hope heard among the trees, on the river, soaring among the stars in the night. Men struggle at birth, through sickness, with old age and death. The world changes, life flows.

Thank you Lord for another day. Help my brother along his way, please; bring peace, to the soul. Grant us all peace, serenity and the courage to change.

Bookmark and Share

→ 1 CommentTags: ····

A Picture’s Worth A 1,000 Words

August 7th, 2010 · Rants, Raves and the Zen Art of Road Trip Management

Those of you who have read through our stories here know that pictures are a big part of the last great road trip. And like boho chic runway models you will find one or two of our images that better than average. But most of the time I rely on point shoot… shoot a lot and hope something interesting comes out.

But when I see someone with an eye for composition and an editing flare I realize I just hack at it…

You know who they are. Artist who tell their stories with a single image. William Shafer (Raggler on Flickr) is one of those guys who tells his stories with pixels. Stories that convey moods and transmits an energy without ever writing a single word. When I look at these images my soul changes.

For me there are hundreds of stories in each of these images. I don’t necessarily see only Raggler’s story… I see mine. I look into these images and I feel my past adventures and I imagine adventures still to come, I take his story and make it my own.

When I first came across Raggler’s images I felt the need to travel… around the block, around the world, it didn’t matter I just needed to travel. I see these images and sense the energy of the road, I hear the road calling to me, I feel its pull on my life.

My life has been dragged across blacktop and dirt around the world. I’ve encircled the globe four times, seen 17,504 sun rises and loved deeply.  I’ve driven to places I shouldn’t have and met people who surprised me in so many wonderful ways. My life stories are spread across the Internet and tattooed in flesh. But it is images like these that humble me. I see these images and know I have to keep moving.

Until the other day I didn’t know Raggler but now he’s inspired me to create better stories in life, words and images.

…Ok this one, just screams Hula Betty to me! What do you think?

Thank you Raggler for sharing your images and allowing us to post them here.

Bookmark and Share

→ 4 CommentsTags: ·····

Naches 4×4 Adventure Video

August 2nd, 2010 · Trail Runs

When we go on a 4×4 adventure the video camera is always on…  After three days with the NWFJCC in the Naches Area we had hours of video.  One of the great things is that I get to see all the fun times and relive the adventure.  And even though I watched all the hours I know you don’t want to…  come on be honest… you can only watch rigs and listen to me babble so long before the drone of engines and my voice puts you into a catatonic schizophrenia, give me a gun suicidal state of mind.

So here is ten minutes of three days in the Naches Area…  be sure to check out breakfast and see some of the cast of players on this adventure.

Naches Off Road Area from Hula Betty on Vimeo.

Bookmark and Share

→ 2 CommentsTags: ··········

Naches Day 4 (Ain’t Had Enough Fun)

July 27th, 2010 · Trail Runs

The shortest distance between two points is a straight line… And yes for all you math majors in the crowd I know a line is straight by definition and a straight line is redundant but that is just how the saying goes.

Late last night around the fire we came up with the idea of a fancy sit down breakfast… Eggs, bacon, english muffins, patties of foil wrapped butter, jam in little single serving tubs, OJ in glasses, endless pots of hot coffee, real dishes,  silverware and waitresses who magically appear when your water glass is empty. Half a dozen rigs descended on Whistlin’ Jack lodge.  It wasn’t a pretty sight. Sure we’d washed off the top layer of dirt the night before, but this was still a pretty ragtag looking group.

Over the sound of clinking glasses, knocking dishes and silverware, ten different conversations were going on at once. Couples telling the stories about how they met, their pet names for each other like “funny retard”, who was looking for a new job and what was planned for the rest of the summer.  Turns out this was the lodge where Curtis and Maryalice were married at not that long ago so we thought about honoring them with a moment of silence… not that we did… but we thought about it.

Eventually the conversation turned to the drive home… Some would be heading east, a few west and a couple south. For the Seattle bound crew the idea was pretty simple… Rather than head around the mountain on highway 410, lets go straight over taking the forest roads back to Greenwater.  Now all we had to do was pay the tab, head back to camp, pack up and go.

Have you ever noticed how long goodbyes take when you are having a good time with great people. No one really wanted to go, but home was calling and sooner or later the realities of life would pull us all back in, leaving this weekend as only a fond memory in the minds of all. But we still had the drive over the mountain to look forward to and with four rigs we would make good time, see some beautiful views and stay off the blacktop a little longer.

We headed out cruising west through the woods kicking up dust and making good time as we turned onto Forest Road-1913.  And than a little trail sign caught our eye… The Naches Wagon Trail is one of the historic trails carved out of the hillside by the pioneers as they dragged their wagons over the mountains looking for a better life in the Pacific Northwest.   Abandon by the wagon train bosses when easier passes were found, today the historic trail is kept open as a 4×4 trail. Opened again to seasonal traffic the day before, this was a sign from the off road adventure trail gods… so left it is.

Sitting in a rig with padded seats, independent suspension,12 inches of flex, 135 horses, loads of torque and you’re still digging your fingers into the steering wheel as you climb long steep hills of loose rock gives you only the slightest idea of what the early pioneers must have endured to drag their wagons up and down the trail. Although marked as an “Easy” section… the trail is definitely aimed at the motor cycles and narrower rigs as we squeezed by the scarred trees.  There were times we’d of thought it was a wide hiking trail if not for the signs.

Even though the trail had just opened the day before, traffic was light with mostly the two wheeled guys working around us as we motored our way through the woods. Reaching the pass, the trail opens up to what can only be described as god’s country. Wide open lush green meadows that must have inspired the pioneers to push on to the valleys below in the land of milk and honey. We stopped to take it all in, pee.. again… and give the blood a chance to flow back into our white knuckles.

The maps say “More Difficult Steep Down Hill” ahead. What the maps don’t say is steep down hill with a giant gnarly stump sticking out of the hill side, its sole purpose to inflict damage on body panels that pass. The paint, wood scars and broken glass give testimonial to the stumps ability to inflict pain. Sensibility had been thrown out long ago, stories remained to be told, Hula Betty was dancing on the dash and there were still one or two tricks to teach these old dogs. Hey this is the historic Naches Wagon Trail and we ain’t had enough fun yet.  We drove on.

At this point I need to bow and pay honor to Brian. I only thanked him a million times but it still feels insufficient. We looked at the stump sticking out, the dip in the trail that throws you into the stump, the up hill slide of loose dirt that throws you into the stump and small foot print size rock that may hold a tire and the fact that as best we could tell, gravity still worked… in the stumps favor. Think camel and eye of the needle… Putting our faith and mental well being in Brian’s hands we followed his spotting directions without question.

Get as close to the stump as you can… By close I mean fold your mirror in, push the driver’s side front tire sidewall into the stump, INCH your way forward. Listen for the pop as your front tire passes by the stump and regains its shape.   At the moment your tire clears the stump you will have just enough room to pass a wisp of paper between your door panel and the stump… HOWEVER, if you’re on the line, your passenger’s side front tire will drop ever so slightly.  Now turn into the stump… yes into the stump and hope your rig flexes ever so slightly away as you keep inching forward and pass your door and quarter panel by before you rub your rear tire against the stump and pop around… Thank you Brian, Thank you… thank you… thank you! Brian managed to work all the rigs pass unscathed… Even ours with it’s extra width front and rear.

There is a certain euphoria that takes over after successfully negotiating an obstacle that appeared impassable. Sure the rest of the trail was filled with branches that added some pin striping to the rig. But nothing that wouldn’t buff out and hell… It adds character.   At least all the sheet metal was straight. We continued to move down the “Steep Hill” testing the rig’s flex and working through a couple more tight squeezes… But nothing like that stump… Finally we popped out onto Forest Road 70 where we had played only weeks before in the snow. We managed to complete the 25 mile run from camp in just under five hours with four rigs and not a single dent or ding… knock on wood. This deserved a celebration…  And we still ain’t had enough fun yet!
